Used 2017 KARATS LR-15N | Lathes CNC, 2-Axis & 3-Axis

Have one to sell?
(847) 669 9781
mike@usedcncllc.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
Lathes CNC, 2-Axis & 3-Axis
Manufacturer:
KARATS
Model:
LR-15N
Year:
2017
Stock #:
9904
Status:
For Sale

Description

KARATS LR-15N Roll Lathe, 2017 model, used condition. Features a substantial 1600.0 swing and 8000.0 centers, ideal for precision work. Reliable choice for your machining needs.

Swing Over Bed63"1,600.2 mm
Machining Length315"8,001 mm
Distance Between Centers315"8,001 mm
Chuck Size 155"1,397 mm
Spindle Speeds 1145 RPM145 RPM
Spindle Horsepower 1134 hp99.9 kW
X - Axis Travel27.5"698.5 mm
Z - Axis Travel315"8,001 mm
Rapid Traverse Rate - X198 in/min.41.5 mm/sec.
Rapid Traverse Rate - Z1197 in/min.83.4 mm/sec.
Gear Ranges22
Tailstock Quill Diameter17.7"449.58 mm
Tailstock Quill Travel11.8"299.72 mm
Tailstock Travel275"6,985 mm
# Axis22
Tailstock'Yes''Yes'
Live Tooling'No''No'
Sub Spindle'No''No'
ControlCNCCNC
Dimensions5600mm x 17500mm5600mm x 17500mm
Weight80000 KG80000 KG
FANUC CONTROL
LAMELLA TOOL POST
