| Swing Over Bed | 20.08" | 510.03 mm |
| Machining Length | 20.08" | 510.03 mm |
| Distance Between Centers | 0" | 0 mm |
| Distance Between Spindles | 0" | 0 mm |
| Chuck Size 1 | 8" | 203.2 mm |
| Spindle Nose 1 | A2 -5 | A2 -5 |
| Spindle Bar Capacity 1 | 2.01" | 51.054 mm |
| Turning Diameter, Shaft Diameter | 9.84" | 249.94 mm |
| Spindle Speeds 1 | 6,000 RPM | 6,000 RPM |
| Spindle Horsepower 1 | 20 hp | 14.9 kW |
| Spindle Bore Diameter 1 | 2.4" | 60.96 mm |
| Rapid Traverse Rate - X1 | 1,181 in/min. | 500 mm/sec. |
| Rapid Traverse Rate - Z1 | 1,471 in/min. | 622.7 mm/sec. |
| Rapid Traverse Rate - C | 400 | 400 |
| Turret Configuration 1 | 12 | 12 |
| Turret Rotary Tool Spindle Speed 1 | 6,000 RPM | 6,000 RPM |
| Turret Rotary Tool Horse Power 1 | 5 hp | |
| Tailstock Quill Diameter | 2.53" | 64.262 mm |
| Tailstock Taper | MT 4 | MT 4 |
| Tailstock Quill Travel | 3.15" | 80.01 mm |
| Programmable Tailstock | YES | YES |
| # Axis | 3 | 3 |
| Bar Capacity | 2.01" | 51.054 mm |
| Tailstock | 'Yes' | 'Yes' |
| Live Tooling | 'Yes' | 'Yes' |
| Sub Spindle | 'No' | 'No' |
| Control | CNC (fanuc) | CNC (fanuc) |
| Weight | 8818 LBS | 8818 LBS |
DOOSAN FANUC SERIES I CNC CONTROL
TOOL PRESETTER
PARTS CATCHER
CHIP CONVEYOR
3 LIVE HOLDERS
BARFEED INTERFACE
ALL AVAILABLE STATIC TOOL HOLDERS
ALL AVAILABLE MANUALS
