| Table Diameter | 15" | 381 mm |
| Table Load Capacity | 1,918 lb | 870 kg |
| Swing Diameter | 36.2" | 919.48 mm |
| Turning Height | 29.5" | 749.3 mm |
| Spindle Nose | A2 - 11 | A2 - 11 |
| Table Speed | 2,000 RPM | 2,000 RPM |
| Main Motor | 50 hp | 37.3 kW |
| Number Of Ranges | 2 | 2 |
| X - Axis Travel | 19.4" | 492.76 mm |
| Z - Axis Travel | 30.7" | 779.78 mm |
| Rapid Traverse Rate - X | 787 ipm | |
| C - Axis Indexing | 0 | 0 |
| W - Axis Cross Rail Travel | 0" | 0 mm |
| W - Axis Cross Rail Positions | 0 | 0 |
| Rotary Spindle Speed | 0 RPM | 0 RPM |
| Rotary Spindle Horsepower | 0 hp | 0 kW |
| Turret Configuration | 12 station | 12 station |
| Automatic Tool Changer | 0 | 0 |
| Machine Weight | 20,723 lb | 9,399.8 kg |
| Weight | 20680.00 | 20680.00 |
FANUC I CNC CONTROL
CHIP CONVEYOR
MANUAL GUIDE I CONVERSATIONAL PROGRAMMING
EMBEDDED ETHERNET FUNCTION
2MB PART PROGRAM STORAGE
DOOSAN TOOL LOAD MONITORING SYSTEM
128 PAIRS OF TOOL OFFSETS
2 SPEED GEAR BOX
CHUCK CLAMP CONFIRMATION
1280 METERS OF PART PROGRAM STORAGE
24" 3 JAW HYDRAULIC CHUCK
