MORI SEIKI SL 250BSMC 3 AXIS CNC LATHE WITH SUB SPINDLE

Swing Over Bed: 26.8"
Turning Diameter, Shaft Diameter: 15.3", 9.7"
Machining Length: 0
Distance Between Centers: 0
Distance Between Spindles: 29.6"
Chuck Size 1, 2: COLLET, COLLET
Spindle Nose 1, 2: A2 -8, A2 - 5
Spindle Bore Diameter 1, 2: 3.2"
Spindle Bar Capacity 1, 2: 2.8"
Spindle Speeds 1, 2: 3500, 4000 RPM
Gear Ranges: 0
Spindle Horsepower 1, 2: 25, 10 HP
Spindle Torque: 0
X - Axis Travel 1, 2: 9.3"
Z - Axis Travel 1, 2: 19.5"
C - Axis Travel 1, 2: .001, .001
W - Axis Travel Sub Spindle: 19.9"
Rapid Traverse Rates X1, X2: 708 IPM
Rapid Traverse Rates Z1, Z2: 945 IPM
Rapid Traverse Rate W Axis: 0
Rapid Traverse C Axis: 0
Turret Configuration 1, 2: 12
Turret Rotary Tool Spindle Speed 1, 2: 3000 RPM
Turret Rotary Tool Horse Power 1, 2: 8.7 HP
Tailstock Quill Diameter: 0
Tailstock Taper: 0
Tailstock Quill Travel: 0
Programmable Tailstock: 0
Tailstock Travel: 0
Machine Weight: 10,560 LBS.
