DOOSAN DNM 200/5AX CNC 5 AXIS VERITICAL MACHINING CENTER

Number Of Tables / Pallets: 1
Table Size : 7.9"
Weight On Table: 132.3 LBS.
Integrated NC Rotary Table Size: 0
Spindle Nose To Table: 1.2" ~ 20.9"
Main Spindle Speeds: 12000 RPM
Main Spindle Taper: 40
Main Spindle Horse Power: 24.8 HP
X - Axis Travel: 15.7"
Y - Axis Travel: 17.1"
Z - Axis Travel: 19.7"
A - Axis Travel: + 30 ~ - 120 DEGREE
B - Axis Travel: 0
C - Axis Travel Table Indexing: 360 DEGREE
Rapid Traverse X, Y, Z: 1417, 1417, 1181 IPM
Cutting Feed Rate: 590.6 IPM
Vertical Turning Table Size, Number Of Tables: 0
Vertical Turning Table Speed: 0
Vertical Turning Table Horse Power: 0
Automatic Tool Changer: 40 ATC
Tool Diameter: 2.9", 4.9"
Tool Length: 11.8"
Tool Weight: 17.6 LBS.
Machine Weight: 12,100 LBS.
